AFRISO DIT 10
For Water
Product Description
Afriso Digital tank contents indicator DIT 10
for water
Specially suitable for continuous level measurement in rainwater tanks and cisterns. For liquid levels from 900 to 4,000 mm.
The hydrostatic level measurement system consists of a display unit with a digital display, a submerged probe, a connection cable (15 m long) and the complete mounting accessories. A 3.6 V lithium battery is used to power the electronic system so that no external power supply is required. The "Push-To-Read" function assures that the measured value is only displayed when the button is pushed. This results in a service life of the battery of approximately five years.
The 4-digit, 12 mm high LCD display is designed to enable reading of the measured values even under adverse light conditions. In addition, it features a convenient set of symbols for maximum user friendliness. The system always calculates the total volume so that that the unit can be chosen as desired.
DIT-10 COMES WITH:
- Control unit with digital display
- 15 m connection cable to probe (cannot be extended)
- Moisture-proof junction box
- Submersible probe with 6m submersible cable
- Screw connector kit G1 x G1½ x G2
- Mounting kit for 15 mm hole (PG 9 gland)
- Wall mounting
Made in Germany
Afriso DIT-10
Displayed Values:
Liters, m³, %, and liquid level in mm
DIT 10 is suitable for use in cisterns and tanks with a filling level from 0.9 to 4 m. No tank chart values need to be entered since all standard tank shapes are stored in the device. Comprehensive additional liter scales are no longer required. The pressure measuring cell obtains a high measuring accuracy of +/- 1.5% FL. DIT 10 provides a menu system for maximum ease of use. The "Push-To-Read" function assures that the measured value is only displayed when it actually needs to be read, thus assuring a service life of the included 3.6 V lithium battery of approx. 5 years. Even under adverse light conditions, the 7 mm LCD display ensures that the litre or cubic meter values are easy to read. An external power supply is not required.
Functions:
Push-to-read, selection of units,
calculation of total volume
Measuring range:
0/400 mbar (5.80psi)
Display:
4-digit, 12 mm high LCD 7-segment display with
additional symbols
Measuring accuracy:
±1.5 % FS
Submersible Probe
Housing: Stainless steel 303
Cable: FEP, 6 m with breather tube
Diaphragm: Ceramics
Seals: FKM (Viton)
Spacer: POM, PE
Supply voltage:
1 x lithium battery 3.6 V (included)
Battery Service life: approx. 5 years
ORDER INFO
(6-WEEK LEAD TIME)
Afriso DIT- 10 Digital Tank Contents Indicator for Water- complete kit
Order # 52124..........$359
